What is EN 1149-5 standard?

The EN 1149-5 standard defines requirements for electrostatic discharge protective clothing. This standard ensures that clothing minimizes static electricity buildup, reducing the risk of sparks that could ignite flammable substances. It applies to industries like petrochemicals, explosives, and electronics manufacturing, where static sparks pose a serious safety risk. In this article, we’ll explore the specifics of EN 1149-5 and its role in workplace safety.

Surface Resistivity Explained (EN 1149-1)

Surface resistivity measures the electrical resistance of a fabric’s surface to assess its ability to dissipate static electricity. In the test, electrodes are placed on the fabric, and a known voltage is applied. The current flowing through the surface is then measured. Surface resistivity is expressed in ohms per square (Ω). For compliance with EN 1149-1, the fabric’s surface resistivity must be ≤ 2.5 × 10^9 Ω.

Charge Decay Explained (EN 1149-3)

Charge decay, as outlined in EN 1149-3, measures how quickly a fabric dissipates static electricity. The test involves charging the fabric with static electricity and then timing how long it takes for the charge to dissipate. The decay time reflects the material’s ability to neutralize static charges. A fabric meets the standard if it can dissipate at least 90% of the charge within 2 seconds or demonstrates a half-decay time of less than 4 seconds.

How to Read Markings of EN 1149-5 Standard

The EN 1149-5 standard markings indicate compliance with electrostatic discharge protective requirements. The marking will typically include “EN 1149-5” to denote the standard itself, followed by references to EN 1149-1 and/or EN 1149-3, which outline specific test methods. If “EN 1149-1” is present, it confirms that the fabric meets surface resistivity requirements, meaning surface resistivity is ≤ 2.5 × 10^9 Ω. If “EN 1149-3” is listed, it indicates compliance with charge decay requirements, meaning the material dissipates at least 90% of the static charge within 2 seconds or has a half-decay time of less than 4 seconds. These numbers provide a clear indication that the garment is suitable for use in environments where static control is crucial.

Where Are Products with EN 1149-5 Standard Used?

Products with the EN 1149-5 standard are used in industries where static electricity poses a fire or explosion risk. Workers in petrochemical plants wear these garments to prevent static sparks while handling flammable liquids. In the explosives industry, personnel rely on EN 1149-5 clothing to reduce the risk of accidental ignition. In cleanrooms and electronics manufacturing, these garments protect sensitive equipment from electrostatic discharge. Additionally, oil and gas refinery workers use them to safely handle volatile substances.

Conclusion

The EN 1149-5 standard ensures protective clothing can effectively prevent static discharge in hazardous environments. Understanding the markings and test criteria of EN 1149-1 and EN 1149-3 helps you select the right gear for your specific safety needs. Whether in petrochemicals, explosives, or electronics manufacturing, EN 1149-5 garments provide essential protection against static electricity risks. Choose compliant products to keep your team safe.
